公称通径
mm |
波数 |
轴向补偿器mm/轴向刚度N/mm |
有效面积
cm2 |
接管尺寸 |
产品长度
mm |
| 0.25MPa |
0.6MPa |
1.0MPa |
1.6MPa |
2.5MPa |
| 100 |
4 |
23/230 |
18/257 |
15/417 |
12/720 |
9.6/1126 |
147 |
?108×6 |
300
|
| 8 |
46/115 |
13/128 |
30/209 |
24/360 |
19/563 |
380 |
| 125 |
4 |
24/270 |
20/300 |
16/494 |
11/1206 |
9/1894 |
1920 |
?133×6 |
300 |
| 8 |
48/135 |
40/150 |
32/247 |
22/603 |
18/897 |
380 |
| 150 |
4 |
24/275 |
20/315 |
16/514 |
11/1606 |
9/2294 |
272 |
?159×6 |
300 |
| 8 |
48/138 |
40/158 |
32/257 |
22/803 |
18/1147 |
380 |
| 200 |
4 |
40/210 |
28/344 |
21/594 |
20/979 |
14/2246 |
498 |
?219×8 |
380 |
| 8 |
80/105 |
56/172 |
42/297 |
40/490 |
28/1123 |
500 |
| 250 |
4 |
40/264 |
30/416 |
28/488 |
20/1726 |
14/2308 |
764 |
?273×8 |
380 |
| 8 |
80/132 |
60/208 |
56/244 |
40/863 |
28/1154 |
500 |
| 300 |
4 |
46/220 |
35/432 |
27/780 |
21/1788 |
17/3494 |
1051 |
?325×8 |
430 |
| 8 |
92/110 |
70/216 |
54/390 |
42/894 |
34/1747 |
580 |
| 350 |
4 |
46/238 |
35/454 |
27/892 |
21/1864 |
17/3562 |
1326 |
?377×8 |
430 |
| 8 |
92/119 |
70/227 |
54/446 |
42/932 |
34/1781 |
580 |
| 400 |
4 |
46/262 |
35/495 |
27/1123 |
21/1633 |
17/4359 |
1613 |
?426×8 |
430 |
| 8 |
92/131 |
70/248 |
54/562 |
42/817 |
34/2180 |
580 |
| 450 |
4 |
52/290 |
36/527 |
28/1168 |
24/1957 |
19/4886 |
2025 |
?478×8 |
430 |
| 8 |
104/145 |
56/264 |
56/584 |
48/979 |
38/2443 |
580 |
|
